Clarke Metal Services are proud to be the sole UK sales agents for Tillmann Gruppe giving us exclusive access to World Class roll forming facilities.


Cold roll forming is the process of passing coiled steel strip through a rolling mill containing a series of pre-designed lower and upper rolls that gradually and progressively add bends and contours to the strip in order to manufacture the required final profile.


Advantages offered by cold rolling:


  • Highly accurate continuous process offering a repeatable quality product.

  • Vast range of profile shape customisation possibilities.

  • Long length capability of up to 25m.


A range of value added processes are also available including hole punching, notching, zinc plating, painting, laser welding and laser profiling.


Our sections are utilised by a very diverse range of market sectors including but not limited to:


  • Automotive

  • Lorry trailers and agricultural trailers.

  • The energy sector encompassing renewable energy such as wind and solar

  • Mechanical and electrical engineering

  • Industrial doors

  • Conveyor technology

  • Racking, shelving and shop fitting

  • Modular Buildings

  • Industrial Greenhouses and Polytunnels

  • Static holiday home sub-chassis

  • Railway engineering

Process Capacity:

Material thickness from 0.3mm to 12mm

Maximum strip width = 1000mm


Hot rolled strip: DD11-DD13, S235JR – S335JR, S315MC-S700MC

Cold rolled strip: DC01-DC06, High strength up to and including ZSTE900

Pre-galvanized: DX51D – DX56D, S220GD – S550GD, HX160YD – HX500LAD

Stainless Steel: 1.4003, 1.4016, 1.4301, 1.4401, 1.4404,1.4571
